Manual Dial Torque Wrenches
SDX-12BP Manual Dial Torque Wrench
Torque Wrenches & Bolt Tightening Tools
- Torque range
- 1–12 N·m
- Overall length
- 305 mm
- Output square drive
- 1/4 in
Product Series
Manual Dial Torque Wrenches
Manual torque wrenches with a direct dial reading for clockwise or counterclockwise torque application.
13 Models
Choosing a Model
Compare Models
Start with the required torque range, then compare fine scale, output square drive, overall length and weight across the thirteen models.
- Work object
- Nuts, bolts and threaded fasteners
- Available Models
- 13 models
- Compare by
- Torque range, Fine scale, Output square drive, Overall length, Weight
Series Models
Choose by Model
Review the model images and key specifications before opening the full product page.
Manual Dial Torque Wrenches
SDX-25BP Manual Dial Torque Wrench
Torque Wrenches & Bolt Tightening Tools
- Torque range
- 3–25 N·m
- Overall length
- 320 mm
- Output square drive
- 3/8 in
Manual Dial Torque Wrenches
SDX-50BP Manual Dial Torque Wrench
Torque Wrenches & Bolt Tightening Tools
- Torque range
- 5–50 N·m
- Overall length
- 355 mm
- Output square drive
- 3/8 in
Manual Dial Torque Wrenches
SDX-100BP Manual Dial Torque Wrench
Torque Wrenches & Bolt Tightening Tools
- Torque range
- 10–100 N·m
- Overall length
- 395 mm
- Output square drive
- 1/2 in
Manual Dial Torque Wrenches
SDX-200BP Manual Dial Torque Wrench
Torque Wrenches & Bolt Tightening Tools
- Torque range
- 20–200 N·m
- Overall length
- 497 mm
- Output square drive
- 1/2 in
Manual Dial Torque Wrenches
SDX-280BP Manual Dial Torque Wrench
Torque Wrenches & Bolt Tightening Tools
- Torque range
- 30–280 N·m
- Overall length
- 690 mm
- Output square drive
- 3/4 in
Manual Dial Torque Wrenches
SDX-420BP Manual Dial Torque Wrench
Torque Wrenches & Bolt Tightening Tools
- Torque range
- 40–420 N·m
- Overall length
- 890 mm
- Output square drive
- 3/4 in
Manual Dial Torque Wrenches
SDX-560BP Manual Dial Torque Wrench
Torque Wrenches & Bolt Tightening Tools
- Torque range
- 50–560 N·m
- Overall length
- 1,100 mm
- Output square drive
- 3/4 in
Manual Dial Torque Wrenches
SDX-700BP Manual Dial Torque Wrench
Torque Wrenches & Bolt Tightening Tools
- Torque range
- 70–700 N·m
- Overall length
- 1,330 mm
- Output square drive
- 3/4 in
Manual Dial Torque Wrenches
SDX-850BP Manual Dial Torque Wrench
Torque Wrenches & Bolt Tightening Tools
- Torque range
- 100–850 N·m
- Overall length
- 1,330 mm
- Output square drive
- 1 in
Manual Dial Torque Wrenches
SDX-1000BP Manual Dial Torque Wrench
Torque Wrenches & Bolt Tightening Tools
- Torque range
- 100–1,000 N·m
- Overall length
- 1,445 mm
- Output square drive
- 1 in
Manual Dial Torque Wrenches
SDX-1500BP Manual Dial Torque Wrench
Torque Wrenches & Bolt Tightening Tools
- Torque range
- 200–1,500 N·m
- Overall length
- 1,445 mm
- Output square drive
- 1 in
Manual Dial Torque Wrenches
SDX-2100BP Manual Dial Torque Wrench
Torque Wrenches & Bolt Tightening Tools
- Torque range
- 300–2,100 N·m
- Overall length
- 1,472 mm
- Output square drive
- 1 in
Model Comparison
Compare Model Specifications
Compare the key specifications below, then open a model for full product details.
Scroll the table horizontally to review every column.
| Model | Torque range | Fine scale | Output square drive | Overall length | Weight | Product page |
|---|---|---|---|---|---|---|
| SDX-12BP | 1–12 N·m | 0.2 N·m | 1/4 in | 305 mm | 0.45 kg | View Model |
| SDX-25BP | 3–25 N·m | 0.5 N·m | 3/8 in | 320 mm | 0.5 kg | View Model |
| SDX-50BP | 5–50 N·m | 0.5 N·m | 3/8 in | 355 mm | 0.55 kg | View Model |
| SDX-100BP | 10–100 N·m | 1 N·m | 1/2 in | 395 mm | 0.6 kg | View Model |
| SDX-200BP | 20–200 N·m | 2 N·m | 1/2 in | 497 mm | 0.8 kg | View Model |
| SDX-280BP | 30–280 N·m | 3 N·m | 3/4 in | 690 mm | 1.35 kg | View Model |
| SDX-420BP | 40–420 N·m | 5 N·m | 3/4 in | 890 mm | 2.45 kg | View Model |
| SDX-560BP | 50–560 N·m | 5 N·m | 3/4 in | 1,100 mm | 3.85 kg | View Model |
| SDX-700BP | 70–700 N·m | 10 N·m | 3/4 in | 1,330 mm | 4.5 kg | View Model |
| SDX-850BP | 100–850 N·m | 10 N·m | 1 in | 1,330 mm | 4.85 kg | View Model |
| SDX-1000BP | 100–1,000 N·m | 10 N·m | 1 in | 1,445 mm | 5.1 kg | View Model |
| SDX-1500BP | 200–1,500 N·m | 20 N·m | 1 in | 1,445 mm | 5.2 kg | View Model |
| SDX-2100BP | 300–2,100 N·m | 20 N·m | 1 in | 1,472 mm | 5.2 kg | View Model |
Common Questions
Questions Before You Choose
Use these questions to focus your model comparison before you inquire.
How do I choose a dial torque wrench model?
Start with a torque range that covers the required value, then confirm the fine scale, output square drive, overall length and weight in the comparison table.
How is torque read on this series?
The source describes a direct dial reading and states that the dial and pointer should be set to zero before use.
Can the wrench apply torque in both directions?
The source states that this series supports clockwise or counterclockwise torque application.
